Fortinet FortiWiFi 30G Firewall + 5 Year UTP Bundle
Integrated Wireless Security with 5-Year Protection
The FortiWiFi 30G UTP Bundle (FWF-30G-A-BDL-950-60) provides an integrated security and wireless platform for small offices, retail locations, and distributed branch environments. It combines a FortiGate Next-Generation Firewall with dual-band Wi-Fi 6 and built-in SD-WAN to secure and optimize internet and application access from a single FortiOS operating system.
With FortiGuard AI-Powered Security Services support, the FortiWiFi 30G series helps protect against modern threats such as intrusion attempts, malware, and web-based attacks while enabling centralized operations and consistent policy enforcement across sites. Its compact desktop form factor also supports optional wall mounting for flexible deployment.
Key Benefits & Features
- UTP Bundle License: Supports FortiGuard security services such as IPS, anti-malware protection, and web/DNS security services (service components depend on the bundle license).
- High-Speed Wi-Fi 6: Integrated dual-band 802.11 a/b/g/n/ac/ax wireless interface for branch and small office connectivity.
- Secure SD-WAN ASIC SP4: Purpose-built acceleration for converged networking and security with optimized performance and efficiency.
- Enterprise Traffic Mix Performance: Up to 800 Mbps IPS throughput and up to 570 Mbps NGFW throughput for real-world security inspection.
- Secure SD-WAN: Built-in SD-WAN capabilities help prioritize and steer application traffic across WAN links for better user experience.
- Compact Form Factor: Desktop design with optional wall-mounting support for space-efficient deployments.
- Unified Management: Manage networking and security policies through a single FortiOS-based interface for simplified operations.
Ideal Use Cases
- Retail Stores requiring integrated security and secure Wi-Fi
- Small Branch Offices needing turnkey security and connectivity
- Remote Workers requiring enterprise-grade protection at home
- Deployments where bundled security services are preferred
Technical Specifications
- IPS Throughput (Enterprise Mix): 800 Mbps
- NGFW Throughput (Enterprise Mix): 570 Mbps
- SSL Inspection Throughput (IPS, avg. HTTPS): 400 Mbps
- IPsec VPN Throughput (512 byte): 3.5 Gbps
- Concurrent Sessions (TCP): 600,000
- New Sessions/Second: 30,000
- Application Control Throughput (HTTP 64K): 830 Mbps
- Operating Environment: 0°C to 40°C (32°F to 104°F), 20% to 90% non-condensing
Upgrade Your Network Security
Secure your business with the FortiWiFi 30G and a UTP bundle license for integrated security, SD-WAN, and Wi-Fi in one compact appliance.
| Product SKU | FWF-30G-A-BDL-950-60 |
| Bundle Type | Hardware + UTP Bundle |
| Form Factor | Desktop |
| Wi-Fi Standard | Dual Radio (2.4 GHz / 5 GHz), 802.11 a/b/g/n/ac/ax (Wi-Fi 6) |
| Firewall Throughput | 4 / 4 / 3.9 Gbps (1518 / 512 / 64 byte, UDP) |
| Threat Protection Throughput | 500 Mbps |
| Network Interfaces | 4x GE RJ45 Ports (1x WAN, 2x LAN, 1x FortiLink) |
| Dimensions (H x W x L) | 1.6 x 5.6 x 6.3 inches (40.5 x 142 x 160 mm) |
| Weight | 1.5 lbs (0.7 kg) |
| Power Input | 12VDC, 2A (Powered by external DC power adapter) |
| System Performance | |
| IPS Throughput | 800 Mbps |
| NGFW Throughput | 570 Mbps |
| Wireless Specifications | |
| MIMO | Dual-stream |
| Antenna Type | 3x WiFi Antenna Ports |
| System Capacity | |
| Concurrent Sessions (TCP) | 600,000 |
| New Sessions/Second (TCP) | 30,000 |
| Firewall Policies | 2,000 |
| Hardware & Environment | |
| USB Ports | — |
| Console Port | 1x Console Port (RJ45) |
| Power Consumption (Avg / Max) | 11.3 W / 13.6 W |
| Heat Dissipation | 46 BTU/hr |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Storage Temperature | -31°F to 158°F (-35°C to 70°C) |
| Humidity | 20% to 90% non-condensing |
| Noise Level | N/A |
| Included Hardware | FortiWiFi 30G Device |
| Included Services | 5 Year UTP Bundle with FortiGuard Unified Threat Protection services and FortiCare Premium |
| Optional Accessories | Wall Mount Kit (SP-FG60F-MOUNT-20), AC Power Adaptor (SP-FG-30G-PA-10(-XX)) |
