Fortinet FS-124F Switch

Name: Fortinet FS-124F Switch
Brand: Fortinet
SKU: FS-124F-NEW
Price: 645.0 USD
Availability: InStock

Part Number: FS-124F

Technical Details

FortiSwitch-124F is a performance/price competitive switch with 24x GE port + 4x SFP+ port + 1x RJ45 console. Fanless design.

$765.00

$645.00

16% OFF

You Save: $120.00

Ask an Expert

sales@networkdevicesinc.com

1-201-559-1474

Availability: In Stock

Condition: Brand New Sealed

Free Shipping on Orders $100+Arrives in 1-6 business days within the U.S.

International DeliveryWorldwide shipping in 7–15 business days

30 Days Return

12 Months Warranty Support

sales@networkdevicesinc.com

1-201-559-1474

Fortinet FS-124F Switch

The FS-124F is a fanless, stackable switch with 128 Gbps of switching capacity. It is ideal for SD-Branch and campus deployments, as it can be used in integration with your FortiGate NGFW by using the management protocol FortiLink. It supports non-FortiLink deployments as well.

Quick Specs:

24x GE RJ45 ports
4x 10GE SFP+ uplink ports
Rack-mountable
Non-PoE

Please see the related tabs for the FS-124F datasheet and compatible accessories.

Properties

Properties	FS-124F
Description	Layer 2 FortiGate switch controller compatible switch with 24 GE RJ45 + 4 10G SFP+ ports. Fanless.
Product Family	FortiSwitch
Product Type	Switch
Total Network Interfaces	24x GE RJ45 and 4x 10GE SFP+
Dedicated Management 10/100/1000 Ports	0
RJ-45 Serial Console Port	1
Form Factor	1 RU Rack Mount
Power over Ethernet (PoE) Ports	0
PoE Power Budget (single/dual PSU)	0
Mean Time Between Failures	> 10 years

Specifications

Switching Capacity (Duplex)	128 Gbps
Packets Per Second (Duplex)	190 Mpps
MAC Address Storage	32 K
Network Latency	< 1µs
VLANs Supported	4 K
Link Aggregation Group Size	8
Total Link Aggregation Groups	16
Packet Buffers	2 MB
DRAM	512 MB DDR3
FLASH	64 MB
ACL	768
Spanning Tree Instances	16
Route Entries (IPv4/IPv6)	-
Multicast Route Entries	-
Host Entries	-
Dimensions in.	1.73 x 9.06 x 12.99
Power Required	100240V AC, 50-60 Hz
Power Supply	AC built in
Redundant Power	No
Power Consumption (Average / Maximum)	24.8 W / 26.3 W
Heat Dissipation	89.683 BTU/h
Operating Temperature	32°113°F (0°45°C)
Certification	FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2
