Fluke 375 FC True-RMS AC/DC Clamp Meter

The Fluke 375 FC True-RMS Clamp Meter offers advanced performance for professionals who require precise and reliable electrical testing. Part of the Fluke Connect® wireless family, this meter allows real-time data transmission to your smartphone or tablet, enabling safer testing outside the arc flash zone. With a VFD low-pass filter for accurate motor drive measurements and compatibility with the optional iFlex® probe for expanded current capacity, the 375 FC is ideal for industrial and commercial diagnostics. Capture inrush currents, trend measurements, and share results via the cloud or ShareLive™ video calls — all with a rugged tool designed for field use.

Key Features:

• Fluke Connect® Enabled: Wirelessly view and log measurements from a distance using your mobile device.
• Current Measurement Range: Up to 600 A with fixed jaw, or 2500 A AC with optional iFlex® flexible probe.
• VFD Low-Pass Filter: Enables accurate measurement of variable frequency drive signals.
• True-RMS Accuracy: Reliable performance on non-linear loads and noisy environments.
• Versatile Measurement Capability: AC/DC voltage, current, resistance, frequency, capacitance, and mV DC.
• Min/Max/Avg and Inrush Recording: Captures electrical variations automatically for detailed diagnostics.
• Safety Certified: CAT III 1000 V / CAT IV 600 V for enhanced user protection.
• Compact & Durable: 34 mm jaw opening, IP30-rated casing, and ergonomic design built for field work.
• Included Accessories: Soft carrying case, batteries, test leads, and instruction manual.
• Warranty: Backed by a three-year Fluke warranty.

Technical Specifications:

• AC Current (via jaw): 600.0 A, Accuracy: ±2% ±5 digits (10–100 Hz), ±2.5% ±5 digits (100–500 Hz)
• AC Current (via iFlex®): 2500 A, Accuracy: ±3% ±5 digits (5–500 Hz)
• DC Current: 600.0 A, Accuracy: ±2% ±5 digits
• AC Voltage: 1000 V, Accuracy: ±1.5% ±5 digits
• DC Voltage: 1000 V, Accuracy: ±1% ±5 digits
• mV DC: 500.0 mV, Accuracy: ±1% ±5 digits
• Resistance: Up to 60 kΩ, Accuracy: ±1% ±5 digits
• Capacitance: Up to 1000 μF, Accuracy: ±1% ±4 digits
• Frequency: 5.0 Hz to 500.0 Hz, Accuracy: ±0.5% ±5 digits
• Jaw Opening: 34 mm
• Dimensions (L x W x H): 249 x 85 x 45 mm
• Weight: 395 g
• Battery: 2 AA alkaline batteries
• Operating Temperature: -10°C to +50°C
• Safety Rating: CAT III 1000 V / CAT IV 600 V (IEC 61010-1, 61010-2-032)
• IP Rating: IP30 (non-operating)
