The FortiGate 70G-BDL-809-36 bundle runs on FortiOS, the industry's first converged networking and security operating system, enabling businesses to gain benefits of operational efficiency and unified protection. As a cornerstone of the Fortinet Security Fabric platform, the FortiGate firewall works seamlessly with FortiGuard AI-Powered Security Services to deliver coordinated, automated, end-to-end threat protection in real time.
The 70G family is built on the patented SD-WAN-based ASIC SP5, which delivers unmatched performance over traditional CPUs with lower cost and reduced power consumption. This application-specific design and embedded multi-core processor further accelerate the convergence of networking and security functions in the 70G family to optimize secure connections and deliver a robust user experience at branch locations.
Converged Next-Generation Firewall and SD-WAN
Key Benefits
- Unparalleled Performance: Enabled by Fortinet's patented SP5 ASIC and the FortiOS operating system to deliver industry-leading throughput and faster security inspections.
- Enterprise-Grade Protection: Includes FortiCare Premium and FortiGuard Enterprise Protection (3 Year contract) alongside FortiGuard AI-Powered Security Services for real-time, coordinated threat protection.
- Simplified Operations: Centralized management for networking and security with automated workflows, deep analytics, and self-healing capabilities.
- Integrated SD-WAN: Delivers faster application identification to avoid delays and accelerates overlay performance regardless of location.
- Compact & Fanless: Small, lightweight desktop form factor with fanless cooling, suitable for deployment in noise-sensitive environments.
Ideal Use Cases
- Secure Branch: Extends security to WAN, LAN, and WLAN at branch offices for unified protection and reliable connectivity.
- Perimeter Protection: Inspects and controls incoming and outgoing traffic based on defined security policies to guard against defined and unknown threats.
- Secure SD-WAN: Enables best-of-breed WAN edge with integrated SD-WAN, WAN optimization, and security from a single OS.
- Universal ZTNA: Controls access to applications no matter where the user is and no matter where the application is hosted for universal application of access policies.
Technical Specifications Summary
- Firewall throughput (1518 / 512 / 64 byte UDP): 10 / 10 / 10 Gbps
- IPS throughput (Enterprise Mix): 2.5 Gbps
- NGFW throughput: 1.5 Gbps
- Threat Protection throughput: 1.3 Gbps
- IPsec VPN throughput (512 byte): 7.1 Gbps
- SSL inspection throughput (IPS, avg. HTTPS): 1.4 Gbps
- Power input: 12V DC, 3A
- Power consumption (average / maximum): 12.3 W / 12.8 W
- Dimensions (H x W x L): 40.5 x 216 x 160 mm (1.6 x 8.5 x 6.3 in)
- Operating temperature: 0°C to 40°C (32°F to 104°F)
- Interfaces: 10 x GE RJ45 ports (including 2 x WAN, 1 x DMZ, 7 x Internal; 2 x FortiLink by default), 1 x RJ45 console, 1 x USB
- Compliance and certifications: FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB; USGv6/IPv6
Upgrade Your Network Security
Deploy the FortiGate 70G-BDL-809-36 bundle today for a compact, high-performance security solution powered by the SP5 ASIC and backed by FortiCare Premium and FortiGuard Enterprise Protection.
