The Fortinet FortiGate 701G Series Next-Generation Firewall (NGFW) combines artificial intelligence (AI)-powered security and machine learning (ML) to deliver threat protection at any scale. Powered by Fortinet's patented SPU NP7 and the tenth-generation content processor (CP10), the FG-701G delivers ultra-fast threat protection and SSL inspection without impacting performance.
Designed for modern, high-bandwidth networks, the FortiGate 701G features a versatile array of interfaces, including four 25 GE SFP28 slots, four 10 GE SFP+ slots, and eight 5G BASE-T RJ45 ports. It incorporates FortiSentry, an out-of-band hardware module designed to enhance system integrity by continuously monitoring the FortiOS file system integrity. With dual internal AC power supplies included by default, the FG-701G supports resilient deployments in enterprise environments.
Data-Driven Security with 960GB Storage and CP10 Acceleration
Key Benefits
- High-Speed Processing: Delivers 38 Gbps IPS throughput and 29 Gbps NGFW throughput powered by NP7 and CP10.
- Integrated Storage: Includes 2x 480 GB (960 GB total) onboard SSD storage.
- Versatile Connectivity: Equipped with 4x 25 GE SFP28, 4x 10 GE SFP+, and 8x 5G BASE-T RJ45 ports for flexible deployment.
- System Integrity: FortiSentry hardware module continuously monitors FortiOS file system integrity to detect and prevent unauthorized modifications.
- Encrypted Traffic Inspection: Provides 14 Gbps of SSL inspection throughput (IPS, avg. HTTPS) for securing encrypted traffic.
- Operational Resilience: Includes default dual internal power supplies (1+1 redundancy) to maximize uptime.
- AI-Powered Defense: Leverages FortiGuard AI/ML-powered security services for consolidated threat protection.
Ideal Use Cases
- Enterprise Edge Security: High-performance inspection and threat protection for enterprise networks.
- Secure SD-WAN: Converged networking and security for WAN edge transformation and hybrid working models.
- Segmentation: Network segmentation to reduce lateral threats and support hybrid IT environments.
- Hybrid Mesh Firewall: Consistent policy enforcement and threat protection across network segments.
Technical Specifications Summary
- IPS Throughput: 38 Gbps
- NGFW Throughput: 29 Gbps
- Threat Protection Throughput: 26 Gbps
- IPv4 Firewall Throughput (UDP): 164 / 163 / 145 Gbps (1518/512/64 byte)
- IPv6 Firewall Throughput (UDP): 164 / 163 / 145 Gbps (1518/512/86 byte)
- IPsec VPN Throughput (512 byte): 55 Gbps
- SSL-VPN Throughput: 8 Gbps
- SSL Inspection Throughput (IPS, avg. HTTPS): 14 Gbps
- Concurrent Sessions (TCP): 16 Million
- Interfaces: 4x 25 GE SFP28, 4x 10 GE SFP+, 16x 1 GE SFP, 8x 5G BASE-T RJ45, 2x RJ45 (HA/MGMT)
- Onboard Storage: 2x 480 GB (960 GB total)
Upgrade Your Network Security
Enhance your enterprise defense with the high-performance FortiGate 701G.
