The Fortinet FortiGate 4801F-DC is a high-performance Next-Generation Firewall (NGFW) engineered for hyperscale data centers and service providers requiring DC power infrastructure. Built on Fortinet's specialized NP7 and CP9 security processing units, this 4 RU rack mount appliance delivers up to 3.1 Tbps firewall throughput and ultra-low latency as low as 3.6 μs. It is designed to ensure that advanced security inspection can be deployed at scale without becoming a performance bottleneck in high-traffic environments.
Featuring a massive array of high-speed connectivity options, including 8x 400GE/200GE QSFP-DD slots and 12x 200GE/100GE/40GE QSFP56/28 slots, the FG-4801F-DC is built to handle high-volume traffic and elephant flows in modern data center architectures. The device includes 2x 1.92TB internal SSDs for local log storage and reporting, supporting operational visibility in demanding environments. With a dedicated DC power input range of -72V to -40V, it integrates cleanly into telecommunications and data center DC power grids.
Securing Hyperscale Architectures with 400GE Connectivity and DC Power
- 400GE/200GE Connectivity: Features 8x 400GE/200GE QSFP-DD slots to support high-bandwidth data center interconnects.
- Hyperscale Performance: Powered by SPU NP7 and CP9 processors to deliver up to 3.1 Tbps firewall throughput and up to 1.8 billion concurrent sessions with the Hyperscale Firewall License.
- Integrated Internal Storage: Includes 2x 1.92 TB SSDs for local log storage and reporting.
- DC Power Optimization: Designed for DC infrastructures with a -72V to -40V DC input range.
- 4 RU Form Factor: Delivers high interface density within a standard rack footprint.
- Threat Protection Performance: Up to 75 Gbps threat protection throughput.
- Hyperscale Data Centers: Ideal for securing high-volume data center traffic flows.
- Service Providers: Supports high-volume multi-tenant architectures requiring segmentation and high-speed interconnects.
- Telecommunications: Fits into DC-powered carrier networks for 4G/5G and IoT security use cases.
- Latency-Sensitive Networks: 3.6 μs firewall latency supports environments requiring fast packet processing.
- IPv4 Firewall Throughput (1518/512/64 byte, UDP): 3.1 / 3.1 / 0.93 Tbps
- Firewall Latency (64 byte, UDP): 3.6 μs
- IPS Throughput: 87 Gbps
- NGFW Throughput: 77 Gbps
- Threat Protection Throughput: 75 Gbps
- IPsec VPN Throughput (512 byte): 800 Gbps
- SSL-VPN Throughput: 18 Gbps
- Interfaces: 8x QSFP-DD (400GE/200GE/100GE/40GE), 12x QSFP56/28 (200GE/100GE/40GE), 12x SFP56/28 (50GE/25GE/10GE/GE incl. 4x HA/Aux)
- Storage: 2x 1.92 TB SSD
- Power: -72V to -40V DC input; 1622 W average / 1938.2 W maximum
- Physical / Environment / Compliance: 4 RU; 6.89 x 17.13 x 26.10 in; 90.83 lbs; 0°C to 50°C; FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB; USGv6/IPv6
