Canon imageFORMULA DR-M140II Desktop Duplex Document Scanner
Desktop duplex document scanner, 40 ppm / 80 ipm, 600 dpi optical resolution, 80-sheet feeder, U-turn and straight-through paths, USB 2.0
$695.00
Compact Duplex Scanning with Two Paper Paths
The Canon imageFORMULA DR-M140II (DR-M140II) is a desktop sheet-fed scanner that scans in simplex or duplex at speeds up to 40 ppm / 80 ipm in black and white and colour at 300 dpi. An 80-sheet feeder and a suggested daily volume of 6,000 to 8,500 scans support regular batch capture. Documents can travel through a U-turn path for paper from 27 to 128 g/m² or a straight-through path for media from 27 to 255 g/m², business cards up to 380 g/m², and long documents up to 5,588 mm. Windows ISIS/TWAIN drivers are provided with Canon CaptureOnTouch Pro software.
Key Benefits and Features
- Duplex Throughput: 40 ppm / 80 ipm at 300 dpi in both black and white and colour.
- Flexible Feeding: U-turn and straight-through feeding paths with retard roller paper separation.
- Feed Protection: Double feed detection by ultrasonic sensor or by length, with Rapid Recovery.
- Automated Capture: Batch separation by patch code, blank page, counter, barcode, zonal OCR or front page, plus barcode and 2D code recognition.
- Image Processing: Automatic page size detection, deskew, auto colour detection, MultiStream, skip blank page, and bleed-through prevention.
Ideal Use Cases
- Departments and workgroups scanning daily document batches
- Front desks scanning business cards and mixed-weight documents
- Capture workflows using barcode, patch code or zonal OCR batch separation
- Offices scanning long documents up to 5,588 mm
Technical Specifications
- Type: Desktop-type sheet-fed scanner
- Scanning Element: CMOS CIS, 1-line sensor, RGB LED light source
- Optical Resolution: 600 dpi
- Scanning Speed: 40 ppm / 80 ipm (300 dpi), B&W and colour
- Feeder Capacity: 80 sheets
- Document Size: 50.8 to 216 mm wide, 54 to 356 mm long; long document mode up to 5,588 mm
- Interface: High Speed USB 2.0
- Suggested Daily Volume: 6,000 to 8,500 scans/day
- Power Consumption: 24.5 W or less scanning, 1.6 W sleep
- Dimensions and Weight: 313 x 181 x 93 mm (tray closed), approx. 2.6 kg
Order the Canon imageFORMULA DR-M140II Document Scanner
Contact our technical sales team for pricing, availability, and volume orders of the Canon imageFORMULA DR-M140II (DR-M140II) document scanner.
| Brand | Canon |
| Model | imageFORMULA DR-M140II |
| SKU | DR-M140II |
| Product Type | Desktop-type sheet-fed scanner |
| Series | imageFORMULA |
| Form Factor | Desktop |
| Interface | High Speed USB 2.0 |
| Capacity | 80 sheets |
| Speed | Black and white: 40 ppm / 80 ipm (300 dpi); Colour: 40 ppm / 80 ipm (300 dpi) |
| Power | Scanning: 24.5 W or less; sleep mode: 1.6 W; power off: 0.1 W or less |
| Dimensions | Tray closed: 313 x 181 x 93 mm; tray open (feed and back): 313 x 288 x 93 mm |
| Weight | Approx. 2.6 kg |
| Operating Temperature | 10 to 32.5 °C (50 to 90.5 °F) |
| Input Voltage | AC 100 to 240 V, 50/60 Hz |
| Performance | Suggested daily volume: 6,000 to 8,500 scans/day |
| Scanning Element | CMOS CIS, 1-line sensor, RGB LED light source |
| Optical Resolution | 600 dpi |
| Output Resolution | 100, 150, 200, 240, 300, 400, 600, 1200 dpi |
| Output Modes | Black and white, error diffusion, Advanced Text Enhancement, Advanced Text Enhancement II, 8-bit greyscale (256 levels), 24-bit colour, auto colour detection, active threshold |
| Scanning Sides | Simplex / duplex / skip blank page / folio |
| Document Size | Width: 50.8 to 216 mm; Length: 54 to 356 mm; Long document mode: up to 5,588 mm |
| Document Thickness | U-turn: 27 to 128 g/m² (0.04 to 0.15 mm); Straight-through: 27 to 255 g/m² (0.04 to 0.3 mm) |
| Business Cards | Straight-through only: width 50.8 to 91 mm, 380 g/m² (0.45 mm) or less |
| Feeding Paths | U-turn and straight-through |
| Paper Separation | Retard roller method |
| Connector Type | USB 2.0 |
| Voltage Range | AC 100 to 240 V |
| Power Consumption | Scanning: 24.5 W or less; Sleep mode: 1.6 W; Power off: 0.1 W or less |
| Certifications | RoHS |
| Environmental Conditions | 10 to 32.5 °C, 20 to 80% RH |
| Feed Protection | Double feed detection (ultrasonic sensor / by length), Rapid Recovery |
| Software (Windows) | ISIS/TWAIN driver, CaptureOnTouch Pro |
| Optional Module | A4 Flatbed Scanner Unit 102, A3 Flatbed Scanner Unit 202 |
| Replacement Part | Exchange Roller Kit |
