MikroTik CSS606-1G-2Gi-3S+OUT GPERx6 Outdoor Switch

Part Number: CSS606-1G-2GI-3S-OUT

Technical Details

Outdoor IP66 switch, 3x Gigabit Ethernet, 3x 10G SFP+, PoE in and out, DC outputs, SwOS managed
$137.00
-
+

Extend Power and Fiber Anywhere with One Rugged Device

The MikroTik GPERx6 (CSS606-1G-2GI-3S+OUT) is purpose-built for outdoor and long-distance deployments where power and data must travel together reliably. Designed for harsh environments, it combines high-speed fiber switching, flexible power distribution, and an IP66-rated enclosure to simplify complex edge installations.

Using hybrid fiber and copper cabling, the GPERx6 delivers high-speed uplinks and centralized power over distances of up to 1 to 2 kilometers. At the remote endpoint, it intelligently separates fiber, PoE, and DC power to support access points, switches, IoT devices, and specialized hardware.

Key Benefits & Features

  • Hybrid fiber and power distribution: Transmit high-speed data over fiber while delivering DC power over copper within a single cable run.
  • Flexible power outputs: Supports PoE-in, dual PoE-out ports, a 2-pin DC terminal, and three dedicated DC-out ports for non-PoE devices.
  • High-speed fiber connectivity: Three 10G SFP+ ports powered by a dedicated 10G switch chip ensure reliable long-distance uplinks.
  • Rugged outdoor enclosure: IP66-certified housing protects against dust, water, heat, and freezing conditions.
  • Efficient Layer 2 management: Runs MikroTik SwOS for simple and stable switch configuration.

Ideal Use Cases

  • Outdoor perimeter surveillance networks
  • Campus and industrial park fiber extensions
  • Remote wireless access point backhaul
  • IoT and sensor deployments without PoE support
  • Solar-powered or off-grid edge installations

Power Long Distance Networks with Confidence

Order today and simplify outdoor fiber and power deployments with MikroTik GPERx6.

Properties

Model CSS606-1G-2GI-3S+OUT (GPERx6)
Product Type Outdoor Ethernet Switch
Ethernet Ports 3x Gigabit Ethernet
SFP+ Ports 3x 10G SFP+
Switch Chip 88E6193X
Operating System SwOS
Enclosure Rating IP66
Dimensions 406 x 116 x 76 mm
Operating Temperature -40°C to +70°C
Power Consumption (Idle) 6 W (without attachments)
Maximum Power Consumption 160 W

Specifications

PoE-In 802.3bt
PoE-In Voltage 42-57 V
DC Input Voltage 12-57 V (2-pin screw terminal)
PoE-Out Passive PoE up to 57 V (Ether2, Ether3)
Max Output per Port (Input < 30 V) 1.2 A
Max Output per Port (Input > 30 V) 0.625 A
Max Total PoE-Out 2.4 A
DC-Out Ports 3x DC outputs (DC1-DC3)
Max Total DC-Out 3.6 A
DC Inputs 2 (PoE-In and 2-pin screw terminal)

Accessories

Included Fastening set; Hose clamp
