Sapphire 11306-02-20G Pulse AMD Radeon RX 6700 XT Gaming Graphics Card with 12GB GDDR6

Sapphire Pulse AMD Radeon RX 6700 XT Gaming Graphics Card (11306-02-20G)

The SAPPHIRE PULSE AMD Radeon RX 6700 XT Graphics Card utilizes the robust Dual-X Cooling Technology in conjunction with Intelligent Fan Control to maintain low temperatures and minimize fan noise. The optimized PCB design ensures consistent and reliable performance, effectively reducing PCB temperature and minimizing component signal noise. This product delivers serious 1440p gaming and ultra-high frame rates.

Quick Specs:

• Memory: 12GB/192-bit DDR6. 16Gbps Effective
• GPU: Boost Clock up to 2581MHz
• RDNA 2 Architecture
• 16x PCIe 4.0

Please see the related tabs for the 11306-02-20G datasheet and compatible accessories.

Properties	Sapphire Pulse AMD Radeon RX 6700 XT 11306-02-20G
Description	The SAPPHIRE PULSE AMD Radeon™ RX 6700 XT Graphics Card utilizes cutting-edge Dual-X Cooling Technology and Intelligent Fan Control to maintain optimal temperatures while keeping fan noise to a minimum. With an enhanced PCB layout, it ensures consistent and dependable performance while effectively reducing both PCB temperature and signal interference from components.
Product Type	Gaming Graphics Card
Displays	Maximum 4 Displays
Resolution	HDMI™: 7680×4320 DisplayPort1.4: 7680×4320
Interface	PCI-Express 4.0 x16
Output	1x HDMI  3x DisplayPort
Cooling	Dual Fans
Form Factor	2.2 slot, ATX
Dimension	260(L)X 119.85(W)X 49(H)mm
Power Consumption	230W (Board Power)

Game Index	4K
BIOS Support	UEFI
Memory Size/Bus	12GB GDDR6
Memory Clock	16 Gbps Effective
GPU	AMD Radeon™ RX 6700 XT Graphics Card 7nm GPU AMD RDNA™ 2 Architecture
Engine Clock	Boost Clock: Up to 2581 MHz Game Clock: Up to 2424 MHz Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.
Stream Processors	2560
Infinity Cache	96MB
Ray Accelerators	40
Sapphire Features	Premium Digital Power Design Fuse Protection Dual-X Cooling Technology Intelligent Fan Control Precision Fan Control Metal Backplate Two-Ball Bearing Fans Integrated Cooling Module TriXX Supported TriXX Boost
AMD Features	AMD RDNA™ 2 Gaming Architecture DirectX® 12 Ultimate Hardware Raytracing  Smart Access Memory Infinity Cache 7nm GPU PCI® Express 4.0 Support AMD FreeSync™ Technology DisplayPort™ 1.4 with DSC  HDMI™ 2.1 VRR Video Streaming up to 8K Radeon™ VR Ready Premium AMD FidelityFX Radeon™ Image Sharpening Radeon™ Anti-Lag Radeon™ Software Game Driver Optimizations
OS	Linux®, Windows® 7*, Windows® 10, and Windows 11. 64-bit  operating system required
System Requirement	Minimum 650 Watt Power Supply 1 x 8-pin + 1 x 6-pin Power Connector. PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard. Minimum 8GB of system memory. 16GB recommended.
